358 High Security Anti-Climb Wire Mesh Fence Panel 1.5 m Outdoor Security WPC Frame Clear View Metal Steel For Outdoor Use
358 Fencing Detail
'358' comes from its measurements 3" x 0.5" x 8 gauges which equates to approx. 76.2mm x 12.7mm x 4mm (Length x height x Diameter) in metric.
358 security fences are extremely difficult to penetrate, with the small mesh aperture being effectively finger proof, and extremely difficult to attack using conventional hand tools.
358 High Fencing Specification
|
Wire Thickness
|
3-5mm
|
|
Hole Size
|
76.2*12.7mm center to center
|
|
Fence Panel Width
|
2000mm, 2200mm, 2500mm
|
|
Fence Panel Height
|
1000mm, 1200mm, 1500mm, 1800mm, 2000mm
|
|
Post Length
|
1400mm, 1600mm, 2000mm, 2300mm, 2500mm
|
|
Post Type
|
Square fence post 60*60*2.0/2.5mm, 80*80*2.5/3.0mm
|
|
Fence Fitting
|
Flat bar, metal clips
|
|
Surface Treatment
|
electric galvanized/hot dipped galvanized then powder coated, hot dipped galvanized
|
|
Packing terms
Fence Panels:
1> it has rubber mat at the bottom of the pallet to avoid the pallet destroyed the panels
2> it has 4 metal corners to keep the pallet more strong.
3> it has metal plate under the plastic bandage to reduce the apressure of fence panels.
4> it has wooden plate at the top of fence panel which can protect the fence panels avoid being crushed by other pallets.
Post:
1. Hot dip galvanized surface will loose loading in the container
2. Powder coated single package with bubble wrap
Fittings:
1. Woven bags and carton box
Factory picture
