358 Anti Climb Security Fence Black Powder Coated Clear View
| Place of Origin | Hebei, China |
|---|---|
| Brand Name | Giant Fence |
| Certification | ISO14001:2015/OHSAS 18001:2007/ ISO9001:2015 |
| Model Number | GF020 |
| Minimum Order Quantity | 50sets |
| Price | Negotiable |
| Packaging Details | 1.panel with pallet and post bulk 2.panel and post all packing with pallet |
| Delivery Time | 18-21days |
| Payment Terms | T/T, L/C, D/A, D/P, Western Union, MoneyGram |
| Supply Ability | 5000meter per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Model Number | Anti Climb Fencing For Square Post | Wire Diameter | 3.0/4.0mm |
|---|---|---|---|
| Hole Size | 3''*1/2'' | Post Type | Square Type Post |
| Material | Low Carbon Iron Wire | Package | Plastic Film + Pallet |
| Feature | Anti-cutting And Anti-climbing | Application | School,Jail,Airport |
| Color | Sliver,green | ||
| Highlight | 358 Anti Climb Security Fence,Powder Coated 358 Mesh Fencing,Black 358 Mesh Fencing |
||
Product Description
358 Anti Climb Security Fence Black Powder Coated Clear View Fence For Sale
358 High Security Fence
Anti-climb fence, also called High Security Fence,358 Fence, which is well-known as anti-climb & anti-cut.Using high quality carbon steel wire to weld a fence panel, it can provide privacy in some extent.Giant High security fences are used to give enduring and secure protection for the public buildings,commercial properties etc. High security fence can also be worked with electric alarm, detection systems( no blind spots for CCTV) etc. It is also widely used in military, airports, prisons etc.
Specifications of the panels
| LineWirex crosswire |
HoleSize | Length | Height | BendingNo. | CommonColor | Surfacetreatment |
| 4x3mm 4x4mm 4.5x3mm 4.5x4.5mm |
76.2x12.7mm 75x12mm |
2m 2.2m 2.4m 3m |
1800mm | 3 | Green RAL 6005 Grey RAL 7016 Black RAL 9005 |
1.Hot-dipped galvanized after black wire welded
galvanized wire welded
galvanized wire welded |
| 2000mm | 3/4 | |||||
| 2200mm | 4 | |||||
| 2400mm | 4 | |||||
| 2800mm | 5 | |||||
| 3000mm | 5 |
358 Fence With Square Type Post
| Post view | Size | Thickness | Panel height | Post Length | surface treatment |
| Itype post | 44x70mm 55x100mm |
1.8mm 2mm 2.5mm 3mm |
1830mm | 2400mm | 1.Black tube Hot-dipped galvanized 2.Galvanized tube pvC coated |
| 2030mm | 2500mm | ||||
| 2230mm | 2800mm | ||||
| square post | 50x50mm 6Ox60mm 8Ox80mm 100x100mm |
2430mm | 3000mm | ||
| 2800mm | 3500mm | ||||
| 3000mm | 3700mm |
Details of the parts
Application
-
School
-
power station
-
commonality construction
-
jail
-
airport
-
military base
-
countryborder and other high security area and place
Exra choose the angle steel,babred wire or razor wire fence to make more security.
Feature
- Anti-cutting
- Anti-climbing
- High security
- Beautiful design
- Easy assembled
- Anti - corrosion
Surface Treatment
| Surface Treatment | Min. | Max. | |
| 1 | Electric Galvanized | 8g/m² | 15g/m² |
| 2 | Hot Dipped Galvanized | 40g/m² | 60g/m² |
| 3 | Powders Sparyed Coating | 100 microns | 120 microns |
Produce process
Purchase the raw material wire--Zn/Ai coating test--cutting--welding panel--powder coating or hot dip galvanized--packing--Loading
Post--cutting--punching--powder coating--packing--loading
Clips--packing--loading
Quality Control Process
1. Raw material test the Zn/Ai
2. Semi-finished product test the size and quality
3. Finished Product’s Test the surface adhesive force (usually the post surface test )
4. Finished Product’s installation
