Hebei Giant Metal Technology co.,ltd
| Place of Origin: | Hebei, China |
|---|---|
| Brand Name: | Giant Fence |
| Certification: | ISO14001:2015/OHSAS 18001:2007/ ISO9001:2015 |
| Model Number: | GF019 |
| Minimum Order Quantity: | 50sets |
| Price: | Negotiable |
| Packaging Details: | 1.panel with pallet and post bulk 2.panel and post all packing with pallet |
| Delivery Time: | 18-21days |
| Payment Terms: | T/T, L/C, D/A, D/P, Western Union, MoneyGram |
| Supply Ability: | 5000meter per week |
| Model Number: | RAl6005 Green Security Fence | Wire Diameter: | 4.0mm |
|---|---|---|---|
| Hole Size: | 76.2*12.7mm | Height: | 1.8-5m |
| Length: | 1.5-2.5m | Application: | School,Prison,Airport |
| Color: | Sliver,black,green | Surface: | PVC Coated |
| Feature: | Anti Cut | Packing: | Bulk |
| High Light: | ral6005 green color anti climb fencing,square post anti climb fencing,flat bar 358 anti climb fence |
||
Prison Fence Panels Wire Mesh High Security Anti Climb Security Fencing
Anti Climb Security Fencing Description
Anti climb mesh fence is also called 358 fence( 3"×0.5"×8 guage) also known as"prison mesh"or anti-climb fence,is a special fencing panel,we can make in our city,this production offers the best value for performance, durability and appearance,"358"comes from its measurements 3" x 0.5" x 8 gauge which equates to approx.76.2mm x 12.7mm x 4mm in metric.
358 wire mesh fence is a professional structure designed for high security environments, combined with an steel framework,coated with heavy zinc or RAL color powder coating.
High Security Fencing Specifications
| Panels | post | ||||
| Fence | Panel Size | Post Size | Post Height | Total Number of Fixings | |
| Height | Height/Width | Lenght/Width/Thickness | Inters- 1 clemp | Corners-2 clamp | |
| m | mm | mm | mm | ||
| 2.0 | 2007 x 2515 | 60x60x2.5mm | 2700 | 7 | 14 |
| 2.4 | 2400 x 2515 | 60x60x2.5mm | 3100 | 9 | 18 |
| 3.0 | 2400 x 2515 | 80x80x2.5mm | 3800 | 11 | 22 |
| 3.3 | 2997 x 2515 | 80x80x2.5mm | 4200 | 12 | 24 |
| 3.6 | 3302 x 2515 | 100x60x3mm | 4500 | 13 | 26 |
| 3.6 | 3607 x 2515 | 100x100x3mm | 4500 | 13 | 26 |
| 4.2 | 4204 x 2515 | 100x100x4mm | 5200 | 15 | 30 |
| 4.5 | 4496 x 2515 | 100x100x5mm | 5500 | 16 | 32 |
| 5.2 | 5207 x 2515 | 120x120x5mm | 6200 | 18 | 36 |
High Security Fencing Surface Finish
Hot dipped galvanized
Hot-dip galvanizing is the process of dipping fabricated steel in a bath of molten zinc to form a tightly-bonded alloy coating that provides superior corrosion protection to steel.
Advantages of Hot Dip Galvanizing
More cost effective for long term
Long service life
Low maintenance
Corrosion resistant - a protective coat of armor
Less inspection required on job sites
Self healing (scratches and cuts in coating)
Produce process
Purchase the raw material wire--Zn/Ai coating test--cutting--welding panel--powder coating or hot dip galvanized--packing--Loading
Post--cutting--punching--powder coating--packing--loading
Clips--packing--loading
Packing terms
1. Panel all packing with the pallet (steel pallet or wooden pallet)
2. Clips packing in the carton box
Quality Control Process
1. Raw material test the Zn/Ai
2. Semi-finished product test the size and quality
3. Finished Product’s Test the surface adhesive force (usually the post surface test )
4. Finished Product’s installation
