ISO9001 High 2230mm Anti Scaling Fence I Type Post Anti Climb Mesh Fence
  • ISO9001 High 2230mm Anti Scaling Fence I Type Post Anti Climb Mesh Fence
  • ISO9001 High 2230mm Anti Scaling Fence I Type Post Anti Climb Mesh Fence
  • ISO9001 High 2230mm Anti Scaling Fence I Type Post Anti Climb Mesh Fence

ISO9001 High 2230mm Anti Scaling Fence I Type Post Anti Climb Mesh Fence

Place of Origin Hebei. China
Brand Name Giant Fence
Certification ISO14001:2015/OHSAS 18001:2007/ ISO9001:2015
Model Number GF005
Product Details
Model Number:
I Type Post With 3D Wire Mesh Fence
Wire Diameter:
4.5mm
Opening Size:
55*200mm
Height:
2030/2230mm
Bending No:
4/5
Surface Treatment:
Galvanized+PE Coated
Color:
Green,Black
Post Type:
Dovetail Panels
Metal Type:
Iron
Pressure Treated Wood Type:
Heat Treated
Highlight:

ISO9001 Anti Scaling Fence

,

2230mm Anti Scaling Fence

,

I Type Post Anti Climb Mesh Fence

Payment & Shipping Terms
Minimum Order Quantity
50sets
Price
Negotiable
Packaging Details
1.panel and post all bulk in the container 2.panel with pallet and post bulk 3.panel and post all packing with pallet
Delivery Time
18-21days
Payment Terms
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability
5000meter per week
Product Description

Dovetail Type Post Matched Welded PE Coating 3D Welded Wire Mesh Fence

V Mesh Security Fencing with Dovetail Type Post​ Description



The process of V Mesh Security Fencing is simple, the net itself is welded with high quality galvanized wire, and then again PVC coated ,then through a special column and clipped together, the overall structure is simple and generous. Main market is Europe, and most countries of the world also have some demand .



V Mesh Security Fencing with Dovetail Type Post​ , 3D fence also named V mesh fence or Curve mesh fence, it has simple structure ,easy installation and nice appearance

the panel with curves more stable and stronger.



V Mesh Security Fencing Specification



Color
Green And Customizable
Type
Welded Mesh
Certification
ISO9001
Condition
New
Brand
Giant Fence
Material Type
Q195-Q235
Wire Diamter
2.5-3.0mm
Roll Length
25m
Height
1.0m-2.0m
Mesh
50*50mm or 50*100mm
Post Diameter
48mm or 60mm
Warranty
5-10 Years
Usage
Garden, Park, Highway, Railway, Farmland, Factory
Trademark
Giant Fence
Transport Package
Pallets and PE Packing
Specification
CE BV SGS
Origin
Hebei, China



Specifications of the Dovetail Type Post



Post view Size Thickness Panel height Base post Normal post Surface treatment

Dovetail post



55x65mm

65x95mm

1.0mm

1.1mm

1.2mm

830mm 850mm 1200mm

1.Black tube Hot-dipped galvanized

2.Galvanized tube PVC coated

1030mm 1050mm 1400mm
1230mm 1250mm 1600mm
1530mm 1550mm 2000mm


V Mesh Security Fencing Application

  1. Commercial grounds (Corporation, hotel, supermarket)
  2. Private grounds (Courtyard, Villadom)
  3. Public grounds (Park, zoo, train or bus station, lawn);
  4. Road and transit (Highway, railway or road city transit);
  5. 3D fence is used as decoration or protection for various facilities in industry,agriculture, transport, etc.

V Mesh Security Fencing Feature

  1. There have the Triangle shape Bending on the panel. And the bending No.s depend on the panel’s height
  2. There should be steel and plastic clips using to connect the panel with the post
  3. The post can welded based on the end and also can bury into the ground
  4. The surface can do there types :1) hot dip galvanized after welded 2) Galvanzied+powder coating 3) Galvanzied+PE coating

V Mesh Security Fencing process

1.Purchase the raw material wire--Zn/Ai coating test--Straightening and cutting--welding panel--Bending--Powder coating or PE coating--loading
2.Post cutting--punching hole on the post -- Powder coating--Loading

Quality Control Process

  1. Raw material test the Zn/Ai
  2. Semi-finished product test the size and quality
  3. Finished Product’s Test the surface adhesive force (usually the post surface test )
  4. Finished Product’s installation

Service

1: Product Service
Our products offer 10 YEARS GUARANTEE.

2: Product customization services
We can customize products according to your requirements, including design and drawing.

3: After-sales service
Our after-sales service start immediately after signing the contract.
1.No matter FOB or CIF the price term is we would try our best to find a lowest freight cost for customers' reference.
2.The third-party inspection always gets real and true data from us and we will send production photos to customers if there is no inspection from the third-party.
3.Do our best to help customer arrange the shipment and customs clearance.
4.Installation, maintenance and repair instructions with full information.

Packing terms

  1. Panel and post all bulk in the container
  2. Panel with pallet (steel or wooden material) post packing using bubble film bulk in the container
  3. Panel and post all packing with pallet in the container
  4. All the clips and caps packing in the carton box
