18 Inch Diameter 32 Ft Long Galvanized Razor Barbed Wire Hot Dipped Galvanized Razor Barbed Wire
Razor Barbed Wire Product Description
Razor Barbed Wire is also named concertina coils or razor type barbed wire. It is a kind of modern security fencing materials with better protection and fencing strength made of hot-dipped galvanized steel sheets or stainless steel sheets.
Razor Barbed Wire with beautiful and sharp blades and strong core wire, razor wire has the features of secure fencing, easy installation, age resistance and other properties.
Material for Razor Barbed Wire :Hot dipped Galvanized Sheet and Electro/Hot dipped Galvanized Iron/Steel Wire
Razor Barbed Wire Specifications
1. Wire dia: 2.0-2.5mm
2. Barb length: 10-65mm
3. Barb spacing: 26-100mm
4. Blade style: BTO10, BTO12, BTO22, CBT60. CBT65
5. Barb thickness: 0.5mm
6. Regular size for single loop and concertina razor wire:
7. Cover length: 7m, 8m, 10m, 12m, 15m or customize
8. Out diameter: 450mm, 500mm, 600mm, 730mm, 800mm, 980mm or customize
9. Packing: In coil, waterproof paper inside and woven bags outside, then
By pallet or in bulk. Or in carton. As per your request.
|
Reference
Number
|
Thickness
|
Wire Dia
|
Barb
Length
|
Barb
Width
|
Barb
spacing
|
|
BTO-10
|
0.5±0.05
|
2.5±0.1
|
10±1
|
13±1
|
25±1
|
|
BTO-12
|
0.5±0.05
|
2.5±0.1
|
12±1
|
15±1
|
25±1
|
|
BTO-18
|
0.5±0.05
|
2.5±0.1
|
18±1
|
15±1
|
35±1
|
|
BTO-22
|
0.5±0.05
|
2.5±0.1
|
22±1
|
15±1
|
36±1
|
|
BTO-28
|
0.5±0.05
|
2.5
|
28
|
15
|
46±1
|
|
BTO-30
|
0.5±0.05
|
2.5
|
30
|
18
|
46±1
|
|
CBT-65
|
0.6±0.05
|
2.5±0.1
|
65±2
|
21±1
|
101±2
|
|
Outside Diameter
|
No. of Loops
|
Standard Length per Coil
|
Type
|
Notes
|
|
450mm
|
33
|
8M
|
CBT-65
|
Single coil
|
|
500mm
|
41
|
10M
|
CBT-65
|
Single coil
|
|
700mm
|
41
|
10M
|
CBT-65
|
Single coil
|
|
960mm
|
53
|
13M
|
CBT-65
|
Single coil
|
|
500mm
|
102
|
16M
|
BTO-10.15.22
|
Cross type
|
|
600mm
|
86
|
14M
|
BTO-10.15.22
|
Cross type
|
|
700mm
|
72
|
12M
|
BTO-10.15.22
|
Cross type
|
|
800mm
|
64
|
10M
|
BTO-10.15.22
|
Cross type
|
|
960mm
|
52
|
9M
|
BTO-10.15.22
|
Cross type
|
Sorts of razor tape wire:
1. Single loop razor wire
2. Concertina razor wire
3. Welded razor wire (razor mesh)
4. Flat razor wire
Razor wire plays the role of protection in mines, gardens and apartments, frontier and dentry defence, and enclosure of prisons.
