Green 8m Concertina Barbed Wire BTO-22 Concertina Razor Wire

Place of Origin China
Brand Name Giant fence
Certification ISO9001:2008
Model Number GF116
Minimum Order Quantity 50 rolls
Price Negotiable
Packaging Details 1.packing with wooden pallet 2.bulk on the container
Delivery Time 20-25days
Payment Terms L/C, T/T, Western Union
Supply Ability 50000meter per week

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Powder Coating Concertina Barbed Wire Material Steel
Wire Diameter 2.5mm Surface Powder Coating
Weight 8kg/roll Razor Shape BTO-22
Packing Plastic Inner Woven Bag Out Side Length 8m/roll
Certification ISO9001 Application Top Of The Fence
High Light

8m Concertina Barbed Wire

,

Concertina Barbed Wire BTO-22

,

BTO-22 Concertina Razor Wire

Leave a Message
Product Description

Concertina Powder Coating Razor Barbed Wire For Livestock Fence Panels

Razor wire Product Description



Razor barbed wire is a kind of modern security fencing materials fabricated with razor-sharp steel blade and high-tensile wire.
It can be installed to achieve the result of frightening and stopping to the aggressive perimeter intruders,
with piecing and cutting razor blades mounted at the top of the wall, also the special designs making climbing and touching extremely difficult.
The wire and strip are galvanized or PVC coated to prevent corrosion.

Material:
Galvanized wire and plate
Heavy Zinc coated wire and plate
Stainless steel wire and plate

Process: galvanized steel plate or stainless steel plate punched into certain forms then attached to the steel wire in sharp angle to form the blades.
Barbed Types
: BTO-10 BTO-18 BTO-22 CBT-60 CBT-65



Razor wire Specifications



Model Plate Thickness
mm
Core wire Diameter mm Barb Length
mm
Barb Width
Mm
Barb Spacing
mm
BTO-10 0 .5 +- 0.05 mm 2.5mm 10mm 13mm 26mm
BTO-12 0 .5 +- 0.05 mm 2.5mm 12mm 15mm 26mm
BTO-18 0 .5 +- 0.05 mm 2.5mm 18mm 15mm 38mm
BTO-22 0 .5 +- 0.05 mm 2.5mm 22mm 15mm 38mm
BTO-28 0 .5 +- 0.05 mm 2.5mm 28mm 15mm 53mm
BTO-30 0 .5 +- 0.05 mm 2.5mm 30mm 21mm 54mm
BTO-60 0 .6 +- 0.05 mm 2.5mm 60mm 32mm 102mm
BOT-65 0 .3 +- 0.05 mm 2.5mm 65mm 22mm 102mm



Coil OD
(mm)
NO. of Loops NO. of Clips The Utmost
Length (m)
Barb Type Notes
450 mm 33 - 7-8 m CBT60 CBT65 Single Coil
500 mm 56 - 12-13 m CBT60 CBT65 Single Coil
700 mm 56 - 13-14 m CBT60 CBT65 Single Coil
960 mm 56 - 14-15 m CBT60 CBT65 Single Coil
450 mm 56 3 clips 8-9 m BTO12 18 22 28 30 Cross Type
500 mm 56 3 clips 9-10 m BTO12 18 22 28 30 Cross Type
600 mm 56 3 clips 10-11 m BTO12 18 22 28 30 Cross Type
600 mm 56 5 clips 8-10 m BTO12 18 22 28 30 Cross Type
700 mm 56 5 clips 10-12 m BTO12 18 22 28 30 Cross Type
800 mm 56 5 clips 11-13 m BTO12 18 22 28 30 Cross Type
900 mm 56 5 clips 12-14 m BTO12 18 22 28 30 Cross Type
960 mm 56 5 clips 13-15 m BTO12 18 22 28 30 Cross Type
980 mm 56 5 clips 14-16m BTO12 18 22 28 30 Cross Type



BTO -22 Barbed Wire





Green 8m Concertina Barbed Wire BTO-22 Concertina Razor Wire 0



CBT 65 Razor Wire





Green 8m Concertina Barbed Wire BTO-22 Concertina Razor Wire 1



CBT 60 Razor Wire





Green 8m Concertina Barbed Wire BTO-22 Concertina Razor Wire 2



Razor wire Feature



1. Razor barbed is a kind of modern security fencing materials fabricated with razor-sharp steel blade and high-
tensile wire.
2. Visual and psychological deterrent.
3. Resistance to corrosion.
4. Low price and easy to install.
5. It can be installed to achieve the result of frightening and stopping to the aggressive perimeter intruders, with
piecing and cutting razor blades mounted at the top of the wall, its special designs making climbing and touching
extremely difficult.



Green 8m Concertina Barbed Wire BTO-22 Concertina Razor Wire 3



Applications:


Razor barbed wire is widely used by many countries in military field, prisons, detention houses, government buildings
and other national security facilities. Recently years, barbed tape has apparently become the most popular high-class
fencing wire for not only military and national security applications, but also for cottage and society fence, and other
private buildings.



Green 8m Concertina Barbed Wire BTO-22 Concertina Razor Wire 4

Our Services:



1.Support OEM.

2.Sample: Valid

3.Delivery time: The shortest of production time.
If have stocks, the shipping within 3 days.

4.Payment: T/T, L/C, Western Union.

5.The mode of transportation: Sea shipping, air shipping,International express.


Why choose us?


Professional & experienced company.
Professional design team& excellent sales team for your service;
Quick delivery& superior quality



FAQ



1.How about the price?
Firstly,We are always offer the best price to all of our customers.
The second, the price is based upon the quantity required. Generally speaking, the larger the quantity you request, the better pricing per unit you will receive.

2.Is there quality control on all production lines?
Yes,all production line have adequate quality control

3. Can I get samples from you?
If we have stocks, we are glad send sample to you. But if the specification of your request do not have stocks, we are glad to customize to you basic on the Min order quantity.

4. How long the delivery time?
We will finish the production ASAP.
Production efficiency is as important as product quality

5. Minimum order
We do our best to maintain one of the lowest minimum order amounts in the
industry. Meeting customer's requirement is our ultimate goal



Razor wire Packing terms



Panel all packing with the pallet (steel pallet or wooden pallet) in bulk



Green 8m Concertina Barbed Wire BTO-22 Concertina Razor Wire 5
