Pre Galvanized Fixed Knot Deer Fence 525N/Mm2

Place of Origin China
Brand Name HGMT
Certification ISO9001:2008
Model Number GF137
Minimum Order Quantity 50 sets
Price Negotiable
Packaging Details 1.packing with wooden pallet 2.bulk on the container
Delivery Time 20-25days
Payment Terms L/C, T/T, Western Union
Supply Ability 5000meter per week
Product Details
Name Farm Fence Material Steel
Shape Hinged Knot,fixed Knot Surface 1. Pre-galvanized Tube Welded 2. Hot Dip Galvanized After Welded
Packing Pallet Or Bulk Related Product Farm Gate
High Light

Pre Galvanized Fixed Knot Deer Fence

,

Fixed Knot Deer Fence 525N/Mm2

,

fixed knot field fence

Leave a Message
Product Description

Galvanized Livestock Prevent Hinge Joint Page Wire Farm Field Fence





Farm fence Detail



Farm fence is manufactured in a wide selection of heights and styles featuring a graduated spacing that starts with small openings at the bottom which helps prevent entry from small animals. The hinge-lock knot allows the fencing to give under pressure and spring back into shape.



Specifications of the panels



No. Type Specification Weight(kg) Top and Bottom Wire Dia.(mm) Body Wire(mm)
1 7/150/813/50 102+114+127+140+152+178 19.3 2.5 2.0
2 8/150/813/50 89(75)+89+102++114+127+140+152 20.8 2.5 2.0
3 8/150/902/50 89+102+114+127+140+152+178 21.6 2.5 2.0
4 8/150/1016/50 102+114+127+140+152+178+203 22.6 2.5 2.0
5 8/150/1143/50 114+127+140+152+178+203+229 23.6 2.5 2.0
6 9/150/991/50 89(75)+89+102++114+127+140+152+178 23.9 2.5 2.0
7 9/150/1245/50 102+114+127+140+152+178+203+229 26.0 2.5 2.0
8 10/150/1194/50 89(75)+89+102++114+127+140+152+178+203 27.3 2.5 2.0
9 10/150/1334/50 89+102+114+127+140+152+178+203+229 28.4 2.5 2.0
10 11/150/1422/50 89(75)+89+102+114+127+140+152+178+203+229 30.8 2.5 2.0
Note:The first data in type is the No.of line wire; The second data is horizontal hole size(mm); The third data is the height of the fence(mm); The fourth data is the total length of the fence(mm).

Technical parameters:

Wire diameter and tensile strength:

horizontal wires: diameter 2.5 mm, tensile strength 1100-1300N/mm²

vertical wires: diameter 2.5 mm, tensile strength 600-850N/mm²

knot wires: diameter 2.2 mm, tensile strength 400-525N/mm²

Application



1. For animals feeds

2. Farm places

3. Cattle

4. Horse

5. Sheep



Product Features:


1).With innovative and firm structure, flat surface, uniform opening.
2).Good flexibility, good resistance against pressure, hit, corrosion and weather.
3).Neither loose nor break even when partial cutting or hit occur.
4).Tight rolls and large loading, suitable for exporting.
5).Less weight, easy transport, fast installation, easy maintenance.



Packing terms



1. Panel all packing with the pallet (steel pallet or wooden pallet)

2. Clips packing in the carton box
