Square Based H2m Double Wire Welded Fence 55X200mm
  • Square Based H2m Double Wire Welded Fence 55X200mm
  • Square Based H2m Double Wire Welded Fence 55X200mm
  • Square Based H2m Double Wire Welded Fence 55X200mm
  • Square Based H2m Double Wire Welded Fence 55X200mm
  • Square Based H2m Double Wire Welded Fence 55X200mm
  • Square Based H2m Double Wire Welded Fence 55X200mm

Square Based H2m Double Wire Welded Fence 55X200mm

Place of Origin Hebei,China
Brand Name BD fence
Certification ISO14001:2015/OHSAS 18001:2007/ ISO9001:2015
Model Number GF085
Product Details
Name:
Edge Protection Fence
Specification:
5/4/5 Mm6/5/6mm,8/6/8mm
Length:
2.5m
Height:
2.0m
Treatment:
Powder Coating
Color:
Green,black,etc.
Opening Size:
50*200mm/55*200mm
Fittings:
Plastic And Steel
Based:
Square Based
Packing:
Fittings With Woven Bag
Type Fencing,:
Security Fence, Fence Panels
Origin:
China
Usage:
Construction Fence
Highlight:

H2m Double Wire Welded Fence

,

square based Double Wire Welded Fence

,

pvc coated wire mesh fencing

Payment & Shipping Terms
Minimum Order Quantity
50sets
Price
Negotiable
Packaging Details
1.panel and post all bulk in the container 2.panel with pallet and post bulk 3.panel and post all packing with pallet
Delivery Time
8-15days
Payment Terms
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability
5000meter per week
Product Description

6/5/6 8/6/8 Twin Wire Mesh Fence Double Wire Welded Mesh Fence Panels





Double Wire Mesh Fencing Product



Double Wire Mesh Fence is welded with one vertical wire and two horizontal wires; According to wire thickness, the fence can be divided into 6/5/6 type and 8/6/8 type. This can be strong enough, compared to the normal welded fence panel. It's easy to install, and has great resistance of rust and corrosion; can also extend decades of service life with low maintenance cost.



Welded Double Wire Mesh Fence




Fence Panel
Wire Diameter
8/6/8mm, 6/5/6mm, 5/4/5mm, and material is Q195, Q235
Mesh Size
50*200mm /55*200mm/50*150mm/55*100mm, can be customized
Panel Height
0.4m-3m
Panel Width
2.0m, 2.5m as standard

Surface Treatment
Hot-dipped Galvanized then PVC coated
Electric Galvanized then PVC coated
Hot-dipped Galvanized




Fence Post



Dimensions of Type
Rectangle post/Rectangle post/Peach post/Round post Material is Q195-Q235, Most common is 60x40mm post:
Post (4 options with different sections)
•60x60mm and 50x50mm SHS steel Post
•40x60mm RHS steel post
•50x70 and 70x100 Peach shape post
•48mm and 60mm Round section post
Surface Treatment
Hot-dipped Galvanized then PVC coating Hot-dipped Galvanized
Fence Accessories
Clips/Clamps
Metal Clips and Plastic Clips, there are over 6 type as choice
Caps for Posts
Metal caps or plastic caps





Process



1.Purchase the raw material wire--Zn/Ai coating test--Straightening and cutting--welding panel--Bending--Powder coating or PE coating--loading
2.Post cutting--punching hole on the post -- Powder coating--Loading



Packing terms


Panel and post all bulk in the container
Panel with pallet (steel or wooden material) post packing using bubble film bulk in the container
Panel and post all packing with pallet in the container
All the clips and caps packing in the carton box



Square Based H2m Double Wire Welded Fence 55X200mm 0



Double Wire Mesh Fencing Application



1.Commercial grounds (corporation, hotel, supermarket);

2.Private grounds (courtyard, villas);
3.Public grounds (park, zoo, train or bus station, lawn);
4.Road and transit (highway, railway or road city transit);
5.Used as fencing, decoration or protection for various facilities in industry,agriculture,infrastructure, transport,etc.

Square Based H2m Double Wire Welded Fence 55X200mm 1
